BH Poly Half-Cell/BH-60L9-335-360W Solar Panel
120 cells BH-60L9 half cell poly solar panel 335~360W all with A Grade for on-grid & off-grid use for residential and public rooftop & ground mounting PV Power System.
Electrical Charateristics(STC)
|
Module Type |
BH-60L9 |
BH-60L9 |
BH-60L9 |
BH-60L9 |
BH-60L9 |
BH-60L9 |
|
Maximum Power (Pmax) |
335W |
340W |
345W |
350W |
355W |
360W |
|
Open-circuit Voltage (Voc) |
39.8V |
40.0V |
40.2V |
40.4V |
40.6V |
40.8V |
|
Maximum Power Voltage (Vmp) |
32.4V |
32.6V |
32.8V |
33.0V |
33.2V |
33.4V |
|
Short-circuit Current (Isc) |
10.86A |
10.92A |
10.98A |
11.04A |
11.10A |
11.16A |
|
Maximum Power Current (Imp) |
10.34A |
10.43A |
10.52A |
10.61A |
10.70A |
10.79A |
|
Module Efficiency(%) |
18.39% |
18.66% |
18.94% |
19.21% |
19.49% |
19.76% |
|
Power Tolerance |
0~+5W |
|||||
|
Temperature Coefficient of Isc |
0.05%/℃ |
|||||
|
Temperature Coefficient of Voc |
﹣0.31%/℃ |
|||||
|
Temperature Coefficient of Pmax |
﹣0.37%/℃ |
|||||
|
Standard Test Environment |
Irradiance 1000W/m², Cell Temperature 25℃，Spectrum AM 1.5 |
|||||
Product Characteristics
- Optimal Design Combination 166mm+9BB+Half-cut, higher power output.
- Super Performance & Stable Returns Low current & low hot spot, to ensure module operation optimally.
- Diversified Application Scenarios Strong weather-resistance, suitable for various roof installation.
- Lower LCOE Lower BOS, less installation area.
