BH-M60X10/FS 450~470W 1/3 Cut Low Current High Efficiency Solar Panels
Product Details
|
STC—Electrical Characteristics
|
|||||
|
Module Type
|
BH-M60X10/FS
|
||||
|
Maximum Power (Pmax/W)
|
450
|
455
|
460
|
465
|
470
|
|
Open-circuit Voltage (Voc/V)
|
62.0
|
62.2
|
62.4
|
62.6
|
62.8
|
|
Maximum Power Voltage (Vmp/V)
|
52.4
|
52.6
|
52.8
|
53.0
|
53.2
|
|
Short-circuit Current (Isc/A)
|
9.19
|
9.25
|
9.31
|
9.37
|
9.43
|
|
Maximum Power Current (Imp/A)
|
8.59
|
8.65
|
8.71
|
8.77
|
8.83
|
|
Module Efficiency (%)
|
20.85%
|
21.08%
|
21.32%
|
21.55%
|
21.78%
|
|
Power Tolerance: 0~+5, WTemperature Coefficient of Isc: 0.05%/°C, Temperature Coefficient of Voc: -0.31%/°C, Temperature Coefficient of Pmax: -0.35%/°C
|
|||||
|
Standard Test Environment : Irradiance 1000W/m2, Cell temperature 25°C, Spectrum AM1.5
|
|||||
|
NOCT—Electrical Characteristics
|
|||||
|
Maximum Power (Pmax/W)
|
339
|
342
|
346
|
350
|
354
|
|
Open-circuit Voltage (Voc/V)
|
58.7
|
58.9
|
59.1
|
59.3
|
59.5
|
|
Maximum Power Voltage (Vmp/V)
|
49.6
|
49.8
|
50.0
|
50.2
|
50.4
|
|
Short-circuit Current (Isc/A)
|
7.41
|
7.46
|
7.51
|
7.56
|
7.61
|
|
Maximum Power Current (Imp/A)
|
6.82
|
6.87
|
6.92
|
6.97
|
7.02
|
|
Standard Test Environment : Irradiance 800W/m2, Ambient temperature 20°C, Spectrum AM1.5, Wind speed 1m/s
|
|||||
Advantages
* Low Current, 1/3 cut, boost power generation
* Increase power generation by 6~15%
* Reduce holding pressure by 75%+
* Revolutionary Packaging Technology
* Excellent mechanical load capacity: Wind Load (2400 Pascal) and Snow Load (5400 Pascal)
* Low Current, 1/3 cut, boost power generation
* Increase power generation by 6~15%
* Reduce holding pressure by 75%+
* Revolutionary Packaging Technology
* Excellent mechanical load capacity: Wind Load (2400 Pascal) and Snow Load (5400 Pascal)
Product packaging
